200mm High Intensity Traffic Modules 12-24V
Product Description:
ZAMTAS High Intensity LED Modules are engineered for superior performance in both new and retrofit 200mm and 300mm traffic signal applications. Designed with advanced optical technology, these modules deliver exceptional luminous intensity and uniform visibility under all weather conditions. The optimized LED array ensures maximum brightness with minimal power consumption, while maintaining compliance with EN12368 and AS2144 standards. Ideal for critical intersections and high-traffic areas, ZAMTAS High Intensity Modules provide a durable, energy-efficient solution that enhances road safety and operational reliability.
Product Specification:
| Parameter | Specification |
|---|---|
| Module Colors | Red / Yellow / Green |
| Shape / Size | 200mm (8”) Clear Cover |
| Light Source | High brightness LEDs with integrated optics |
| Protection Rating | IP65 (Moisture and dust tight seal) |
| Power Consumption | < 8 W |
| Typical Dominant Wavelength (nm) | Red: 625 ± 5, Yellow: 590 ± 5, Green: 625 ± 5 |
| Operating Temperature | -30℃ to +60℃ |
| Operating Voltage Range | 12–24V DC |
| Insulation Resistance | ≥ 2 MΩ |
| Housing Material | Polycarbonate (PC) |
Product Dimension:
